Non-contact Torque Transmission Device

•
•
•
•

• Description
• Specification

Description

The magnetic gear is a device for non-contact power transmission using the interaction of the magnetic poles' attraction and repulsion. Magnetic gears are products that are driven in a non-contact state on production lines such as LCD, PDP, PCB, OLED, and SOLARCELL that do not allow fine impurities in a clean environment. Replaces mechanical gears that rely on friction to drive.The magnetic gear is composed of two parts: NdFeB magnet ring and bracket base. The magnetic ring of the magnetic gear is the most important part of the magnetic drive wheel. The height of its magnetic area and the number of teeth determine the torque of the magnetic gear.

Detailed use of materials and dimensions, according to CAD engineering drawings, consultation and customization

Features

1. A non-serrated magnet gear. A contactless-type gear using gravity transmission of magnetic force.
2. Eliminates the problems of “heat · noise · wear · dust · vibration” with contactless-type.
3. Can be manufactured with various fastening methods
4. Precise power control and minimization of vibration and backlash are available with controlling the number of poles.

Purposes

1. Gear for moving conveyor in clean room production line for display, LCD, PDP, OLED, LED, PCB, etc.
2. Special cleaner, drying facility line

Download Product Catlogue
