Description
There are five ways for magnetic gears to transmit power:
right angle magnetic gear
The two magnetic gears are arranged at 90 degrees, which is convenient and simple to install, and is mostly used in horizontal assembly lines；
Parallel Axes Magnetic Gear
The transmission of two shafts in parallel state, when transmitting power, the two adjacent magnetic gears rotate in opposite directions. If the direction needs to be consistent, a transition wheel should be added in the middle.Transmitting power in parallel has a stronger magnetic force than transmitting power vertically；
Magnetic Bevel Gears
It is used to replace the traditional bevel gear, using the principle of repulsion of the same magnetic pole, composed of a magnetic gear and a magnetic disc；
magnetic couplings
magnetic couplings transmit the torque without contact through magnetic
forces between the internal and external rotor；
Magnetic gear hybrid transmission power
More than two ways to transmit power, mix and match together to achieve more functions
Features
- A non-serrated magnet gear. A contactless-type gear using gravity transmission of magnetic force.
- Eliminates the problems of “heat · noise · wear · dust · vibration” with contactless-type.
- Can be manufactured with various fastening methods
- Precise power control and minimization of vibration and backlash are available with controlling the number of poles.
Purposes - Gear for moving conveyor in clean room production line for display, LCD, PDP, OLED, LED, PCB, etc.
- Special cleaner, drying facility line
